Customized UV glue adhesive or UV Resin with UV light curable for clear bonding and sealing
Short Description:
Product Detail
FAQ
Product Tags
Product Description
UV glue, UV resin adhesive is one component, requires no mixing, clear with light yellow and medium viscosity liquid, no solvent and no volatiles. It cured at 365nm (main wavelength) with a smooth surface. It have a great adhesion to many materials: plastic, like PC, PET, PMMA, metal and glass, also have an excellent property, widely used in the bonding, modules sealing application.
Features
- Good bonding strength.
- Low contractibility rate.
- Excellent mechanical property.
- Solvent-free, all the raw materials are environmental.
- Fast cured, one component, requires no mixing, easy to use.
- Special benefit: excellent adhesion to many materials.
- high temperature and humidity resistance.
Data Sheet
| Item | Parameter | |
| Uncured | Appearance | Clear with light yellow liquid |
| Viscosity(mPa*s) | 2000 | |
| Density(g/cm3) | 0.95 | |
| Validity date(month) | 12 | |
| Cured condition | Cured condition (second)(1000mW/cm2 at 365nm) | <5 |
| Cured | Hardness(Shore A) | 65 |
| Tensile strength(N/mm2) | 14 | |
| contractibility rate(%) | 4 | |
| Elongation at break(%) | 9 | |
| Refractive index | 1.46 | |
| Effective transmission (%) | ≥85 | |
| Special benefit | Excellent adhesion to many materials:Plastic like PC, PET, PMMA, metal and glassHigh temperature and humidity resistance
Test: 85°C*48h in water, the property don’t change |
|
Notice
- This product belongs to photosensitive adhesive, so it should be store avoid the light.
- Put on safeguard procedures before operation, such as: work clothes, glove and eyes protector.
- Clean the sealed and bonded products before operation.
- Suggest try a small amount before mass production, because different environment, users and application surface will have different influence.
Packaging & Shipping
Package as you required.
